Winding Drum Level Up by PVE

By: PVE

PVE

Winding Drum Level Up by PVE

Freedom through Masterful Design


The Level Up elevator is designed for the homeowner wanting to craft their dream elevator.  This home elevator is finished with a luxury feel and panoramic views with a modern simple design. Self supporting and ready to be customized to be a showcase within your home. Designed to start on the ground level without the need of a pit for hoistway.  This elevator has a compact footprint and is a self-supported structure that enables endless design possibilities for new construction and existing homes. Dual winding drums provide a smooth quiet ride with proven reliability. Are you ready to travel between floors with grace and comfort?


Safety features include interior lighting and fan, emergency stop and alarm buttons, telephone, power failure UPS battery backup system, manual lowering device, mechanical emergency safeties and electric door interlocks.


Standard Features:

  • Capacity - 500 lb. (200 Series CY & SQ), 825 lb. (300 Series CY)
  • Travel height - 38’ (2-4 stops)
  • Drive System - Dual Winding Drums, Steel Cables, 1.1 Worm Geared Motor
  • Speed - 32fpm
  • Electrical Requirements - 220V/5A/Single Phase & 110v lighting
  • Round Size - 37.75” (CY200) , 53.5” (CY300)
  • Square Size - 36.75” x 36.75” (SQ200)
  • Automatic LED lighting & Cabin Fan
  • Standard Color - Black
  • Manual Doors
  • Car Operating Panel - Up/down buttons, emergency stop and alarm.
  • Slimline Phone

WARRANTY:

12 months limited manufacturer parts warranty. 12 months limited manufacturer service warranty.


Options:

  • Colors - White, Dark Gray, Silver, Taupe, Custom Color
  • Automatic Doors
  • Folding Seat
  • Handrail
  • Remote Control
  • Smart Home Integration
  • Cabin Key Lock
  • iButton Key Fob

Installation

Professional Measure + Installation available in the following areas:

Greater Cincinnati, Greater Dayton, OH, Northern Kentucky, Greater Louisville, KY including Southern Indiana, Kentuckiana, Central Kentucky, Eastern Kentucky, Southern Kentucky, Nashville, and Middle Tennessee.
